OTDR TEKCN TC-300 1310/1550nm 28/26dB SM OTDR with power meter and VFL

OTDR TEKCN TC-300 1310/1550nm 28/26dB SM OTDR with power meter and VFL

Product Description
TC-300 series tester is a comprehensive optical fiber measuring instrument developed by TEKCN (Shenzhen) Technology, to solve the measurement of various parameters of optical fiber. This OTDR is also intergrated with other functions, OPM (optic power meter),LS (Laser source),VFL (Visual Fault Locator) and Event map. ONE MACHINE , TESTING ALL.

Features

• Compact, lightweight, powerful
• Dynamic range up to 42dB in single mode and 26dB in multimode
• Testing distance up to 190 km at 1550nm
• 5.6 inch Touchscreen, TFT
• Dual battery, longer standby time and fast charging
• Graphics data reports can be saved in SD card, transferred to a computer and      ready for printing.
• Minimum event dead zone 0.8m
• Minimum attenuation dead zone 4m
• Maximum sampling resolution: 5cm
• One button test 1310 1550nm dual wavelength
•  Various OTDR modules available for SM, MM, PON network, access network test
• OTDR integrated with OPM, LS, VFL and Event map functions ready

Technical Specifications:
Display	5.6 inch Touchscreen,TFT
Interfaces	USB (Type A)MINI USB,SD card
Batteries	Single battery capacity:7.4V/2500mAh; x2 PCS
Power supply	AC/DC adapter; 100~240v, 50/60Hz
Wavelengths (max. 4 wavelengths)	Single mode			Multimode
Wavelengths (nm)	1310nm 1490nm 1550nm 1625nm 1650nm			850nm 1300nm
Dynamic Range(dB)		26~42dB		20/26dB
Event Dead Zone(m)		0.8m		1.25m
Attenuation Dead Zone (m)		4m		5m
Minimum sampling resolution			0.05m
Maximum sampling point			256,000
linearity			≤0.05dB/dB
Loss resolution			0.001dB
Distance resolution			0.01m
Distance accuracy	±(1m+Range×3×10-5+Sampling resolution) (Regardless of the refractive index)
Memory	>100000
Interface	USB(Type A),MINI USB,SD card
Operating temperature	-10℃~+50℃
Storage temperature	-20℃~+70℃
Relative Humidity	≤95% (No condensation)
Size (Hx Wx D)	215mm×155mm×68mm (8.46 in x 6.10 in x 2.68 in)
Weight	1.1kg (including battery)
VFL module	Laser: 650nm±10nm ; default :10mW Laser safety: Class III B
OPM module	Optic power meter -70~+10dBm (default); Optic power meter -50~+26dBm (optional)
Laser source	Output:-5dBm±2dB,Frequency:CW/270Hz/1KHz/2KHz
GPS/GNSS	Optional
WIFI/Bluetooth	Optional
IOT module	Optional

--------------------------------------------------------------------------------------------------
